Rated Output

   額定輸出

2.0mV/V ±0.1%

Zero Balance

   零點平衡

±1% of rated output

Creep after 30 minutes

   蠕變

±0.03% of rated output

Nonlinearity

   非線性

±0.03% of rated output

Hysteresis

   滯后

±0.03% of rated output

Repeatability

   重復性

±0.03% of rated output

Temp. effect on output

   靈敏度溫漂

≤0.002% of applied output/ºC

Temp. effect on zero

   零點溫漂

≤0.002% of rated output/ºC

Safe Temp. Range

   可用溫度范圍

 -10ºC to + 70ºC

Temp. Compensated

   溫度補償范圍

 150%

Safe Overload

   安全載荷

-10ºC to + 40ºC

Input Impedance

   輸入阻抗

387 ohm ± 20 ohm

Output Impedance

   輸出阻抗

350 ohm ± 5 ohm

Insulation Resistance

   絕緣阻抗

≥5000 M ohm (50V DC)

Rated Excitation

   推薦激勵電壓

10V DC/AC

Maximum Excitation

   最大激勵電壓

15V DC/AC

Cable Length

   導線長度

6m

Cable Color Code

   導線顏色

ed(+E)  Black(-E)  Green(+S)  White(-S)
